DESCRIPTION :

• Frame in white lacquered aluminium profile designed for optimum rigidity.
• White-lacquered aluminum vertical rung panel, rung spacing 95 mm, weight 10.40 kg
• Height 1.22 m - 3 widths available
• Wicket gate pre-set and pre-assembled in factory
• Wicket gate in 6 mm PMMA clear panel or laminated glass
• Height: 1.22 m , width 1 m , weight 25 kg .
• Secure, bevelled system: simultaneous operation of latch and handle.
• Opens outwards , handle position selectable
• Automatic door closure by means of an adjustable spring hinge.

• Permanent locking possible : all gates are equipped with a lock that is mandatory for pools open to the public .

INSTALLATION :

• Pre-assemble the fence by sliding the frames into the grooves of the gate and posts to mark out the ground fixing points.
• Drill
• Fix the base plates with 2 dowels (not supplied )
• Adjust post inclination before final tightening

ADAPTABLE TO ALL POOL SHAPES:

• The design in modules of different widths, and the wicket gate's grooves allowing three possible departures, allow not only the enclosure of standard pools, but also those with variable angles.

STIFFNESS KIT

• Recommended for intensive use

WALL-MOUNTING KIT

• Recommended for connecting gate to wall
